COBE carbon steel seamless pipe ET eddy current automatic testing system weld area

FOB Reference Price:Get Latest Price
$5,000.00 - $200,000.00 / Units | 1 Unit/Units (Min. Order)
Usage:
Auto Testing Machine Hardness Tester Abrasion Tester Drop Tester
Lead Time:
Quantity(Units) 1 - 3 >3
Est. Time(days) 60 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China (Mainland)
Brand Name:
COBE
Model Number:
COBE NDT ET
Power:
Non-destructive testing
Product Name:
Eddy current testing system
Speed:
0-60m/min
Model:
Pipe rotated,probes move and scan right and left
Supply Ability
Supply Ability:
50 Set/Sets per Month
Packaging & Delivery
Packaging Details
in proper woodern box
Port
Xiamen
Lead Time :
Quantity(Units) 1 - 3 >3
Est. Time(days) 60 To be negotiated
Product Description

COBE carbon steel seamless pipe ET eddy current automatic testing system weld area

EDDY CURRENT TESTING PRINCIPLE:

       Eddy current testing is based on the principle of electromagnetic induction. The excitation signal is added to the probe coil. When the probe approaches the metal surface, the alternating magnetic field around the coil generate induced current on the metal surface. For the plate metal, the flow of induction current is in the circle of concentric coils, like vortices, called eddy current. The size, phase and flow form of the eddy are influenced by the electrical conductivity of the specimen. The eddy current will also produce a magnetic field, which in turn makes the impedance of the detection coil change.
        As a result, defects or measurements appear on the surface or near the surface of a conductor. When the metal material changes, it will affect the strength and the score of the eddy current. The changes in the eddy current cause the change of the
voltage and impedance of the coil. According to this change, you can know  the defects and the change of metal materials inside a conductor indirectly.

Advantages of Eddy Current Testing:

Profiled materials and small parts
High temperature testing
No need coupling agent
Detection speed is fast and it is easy to realize automation
High sensitivity
It can detect many parameters of material, such as defect, conductivity, permeability, heat treatment, hardness, workpiece size, thickness, etc.

Application of Eddy Current Test
①Flaw detecting, can detect the flaw on the surface and sub-surface, and some flaw under the coating.
②Material sorting, can detect the conductivity on the nonmetal surface, and the related elements like chemical composition and state of tissue. Therefore, eddy current testing can be successfully used to select alloy and test material, the quality of heat treatment and mechanical properties, etc.
③Thickness measurement, eddy current can be used to test the diameter and thickness.


GANTRY TYPE ET AND UT for large caliber oil pipe:

INTRODUCTION


This off-line ultrasonic testing system can be used for big size tube testing, with high flexible, high system stability characteristics.

Step:Work piece will be neatly put onto the platform→Work pieces will be put onto the orbit by the mechanical hand→Work piece will move to the testing area, then pipe rotated, probes move right and left→when find defects, the instrument will automatic alarm, at the same time, it will display the flaw signal,record and analyse the test results, automatic sort the qualified and unqualified,and then finish the detection.

Inside style ET for all different material pipe--inside style:

Our other system
Our Company

Xiamen COBE NDT Technology Co., Ltd is located in the beautiful coastal city of Xiamen, a domestic first-class high-tech enterprise professional development of non-destructive testing instruments and equipment. It is mainly dedicated to the research and development of the electromagnetic(eddy current, magnetic flux leakage and the magnetic memory),ultrasonic testing, industrial electronic endoscope apparatus and equipment, has gained many national patents, and obtained the national science and technology fund of technology-based SMEs in the technological innovation fund. Products are widely used in aerospace, electric power, oil and gas, metallurgy, machinery and automotive industries.
We are a professional team. Our founding team is graduated from Tsinghua University, Peking University, Harbin Engineering University and other prestigious universities, with many years of NDT R&D, production and management experience. R & D team accounts for more than 50% of the total number, and all with bachelor degree or above.
We are a dedicated team. We firmly believe that brand comes from customer's trust. Only by concentrating can we make good brands.
We are a young team. Our average age is only 30 years old, full of vigor and innovation.
We are a team with dreams. COBE people will work with you
hand in hand with the times, fighting for China's industrial NDT to enter into the world's stage!

Packing & Delivery
Our most professional packaging
Transport of large trucks to the seaport
And international transport cooperation
Features

1.The workpiece rotated at one place, can reduce the shake, and the moving speed of the probe holder can be adjustable, so it is better to control the testing quality.

2.Can be applied to a variety of specifications ofthe size of the workpiece ultrasonic testing.
